The Cable set NC1200 / NC2k is a cable set to connect the NC1200 or NC2k amplifier to our SMPS1200 or SMPS3k power supplies.All needed cables are included.
The cable set loudspeaker FA 1 way is a complete cable set to connect your 1 way Fusion Amp with your loudspeaker. This is the same loudspeaker cable set as supplied with new Fusion Amps.The length of the cable is 125cm.
The Cable set NC100HF is a complete cable set to connect the NC100HF hanger module to your NCxxxMP amplifier module or with the MP-DSP Main.Note: For the connection of the NCxxxMP amplifier module please refer to the "Cable set NCxxxMP".NCore signal cable not included and not needed with the NCxxxMP amplifier range.
Introducing the Fusion OLED Display – the perfect enhancement for all Fusion Amplifier Family models and the DSP3-213. Elevate your audio experience with this sleek display, designed to provide you with essential information at a glance. Whether it's monitoring volume levels, identifying active inputs, accessing presets, or staying informed about any error messages, the Fusion OLED Display ensures that every detail is effortlessly visible from your preferred listening position.
Installing the Fusion OLED Display is a breeze. Designed for external attachment to the speaker cabinet, it comes equipped with double adhesive tape for easy and secure assembly. When integrated into a master-slave configuration, consider placing the display on the master device, especially if you plan to use the Hypex remote (remote not included). Please note that in slave devices, the IR functionality will be disabled while still offering all other benefits.
The Fusion OLED Display includes
• 1 x Fusion OLED Display
• 1 x 5 pin cable 125cm
• 1x Quick guide (Refer to the 'Downloads' tab for the complete User Manual)
Upgrade your audio setup with the Fusion OLED Display – where information meets elegance.
The cable set loudspeaker FA 3 way is a complete cable set to connect your 2 or 3 way Fusion Amp with your loudspeaker. This is the same loudspeaker cable set as supplied with new Fusion Amps. The length of the cables is 125cm.
The Cable set NCxxxMP is a complete cable set to connect the NCxxxMP amplifier to your application. Note: For the connection of the NC100HF please refer to the "Cable set NC100HF". NCore signal cable not included and not needed with the NCxxxMP amplifier range.
50cm balanced signal cable with 4-pin connector also providing the enable signal.
Specifications
The QuietConduit cable design incorporates several refinements over normal balanced cables. A conductive polymer interface layer between the braid shield and the insulation of the signal conductor short-circuits triboelectric currents where they are generating, virtually eliminating microphonic noise pickup.
A secondary benefit of this layer is to improve the electrostatic shielding effectiveness of the braid shield. Another crucial improvement is the elimination of drain wires, which is normally included for ease of termination but which allow shield currents to couple noise asymmetrically into the signal conductors. The geometry of the QuietConduit cable is precisely controlled, insuring that any noise coupling is strictly limited to common mode.
The cable set SMPS3k is a complete set of cables to connect the SMPS3k to one amplifier module. If you want to connect 2 or 3 amplifiers you'll need 2 or 3 cable sets. Cable length: 30cm
Goldplated binding post to connect your loudspeakers with your amplifier chassis. For banana plug, spade plug and bare wire connections. This binding post can be mounted as a set with the black spacer or as two single connectors.
This on-off switch can be used as a main switch for your amplifier cabinet. This snap-in switch can handle 16A at 230V. The mounting hole is 31 x 11mm and ~ 25mm deep including the faston terminals.
50cm balanced signal cable with 4-pin connector also providing the enable signal. Specifications The QuietConduit cable design incorporates several refinements over normal balanced cables. A conductive polymer interface layer between the braid shield and the insulation of the signal conductor short-circuits triboelectric currents where they are generating, virtually eliminating microphonic noise pickup. A secondary benefit of this layer is to improve the electrostatic shielding effectiveness of the braid shield. Another crucial improvement is the elimination of drain wires, which is normally included for ease of termination but which allow shield currents to couple noise asymmetrically into the signal conductors. The geometry of the QuietConduit cable is precisely controlled, insuring that any noise coupling is strictly limited to common mode.
This set of 10 pieces isolated blue fastons can be used for several purposes like connecting your transformer or power supply to your power connector. To mount these on your cable you can use our Faston crimping tool. These Fastons are for cables between 1.5-2.5mm. Fits the UcD series.
This set of 10 pieces isolated red fastons can be used for several purposes like connecting your transformer or power supply to your power connector. To mount these on your cable you can use our Faston crimping tool. These Fastons are for cables between 0.5-1.5mm. Fits the UcD series.
This IEC 60320 C14 power connector with fuse holder can be used in your amplifier housing to connect the mains power to your amplifier supply. This power connector is capable to handle 10A at 230V. At the back are Faston terminals for easy connection. The mounting hole must be 32.5x27mm. Fuse not included.
